Model GW

System Configuration

GW Series

Processor

Intel® Celeron J6412 / N Series-N100 /

12th Generation Core I3/I5 Processor

Memory

DDR4 SO-DIMM x1,Default 4GB,Max 16GB (J6412 and N100)

DDR4 SO-DIMM x2,Default 8GB,Max 64GB (12th Generation Core I3/I5 )

Storage

M.2 M-KEY SSD ,Default 128GB,Max 512GB

Power supply

DC 12V/5A 60W power adapter AC100 to 240V full range

O/S compatibility

Windows 10/11 IoT LTSC

Physical Dimensions (W*H*D)

H:630mm x W:400mm x D:225mm

System Weight (with stand)

11.2KG

Operation Temperature

0°C ~ 40°C

Wall Mount

VESA 100x100mm compliant

Product certification

CE / FCC / ROHS / BSMI

LCD & Touch Panel

Main Display

15″ TFT LCD Panel , Brightness : 300 cd/m2, Resolution:1024×768

2nd Display

9.7″~15″ LCD Monitor

Touch

Flat Type Projected Capacitive Multi-Touch (PCAP),USB interface

I/O Connectivity

USB

USB3.0 x 2ports + USB2.0 x 4 ports

LAN

Giga LAN x 1 port

COM

DB9 COM x 2 ports (Extend DB9 COM port x1)

AUDIO

Build in 4ohm/3W speaker x1

HDMI

1port

VGA

1 port

Option

Barcode Scanner

1D and 2D USB interface barcode scanner

POS Printer

57~80mm Thermal Receipt Printer

Keyboard

Programmer/Normal Keyboard

Advertising light box

LED backlight advertising light box(Dimension:340x190mm)

Credit Card Reader Stand

Optional
